Olivetti PGL2645 - With Optional Equipments Attached

286 pages

Save Page as PDF

To Next Page

To Previous Page

2-5

Installing and Setting up the Machine > Part Names

With Optional Equipments Attached

1 Cassette 2

2 Cassette 3

3 Cassette 4

4 Cassette 5

5 Castor kit

6 Bulk Paper Feeder

7 Paper Stopper

8 Rear Tray (PG L2645/PG L2650/PG L2655)

Optional Equipment (page 11-2)
