Olympus E-M1 Mark III User Manual

120 EN
Shooting
2
Role Function
HDR (M)
Enable HDR (P. 152). Press once to enable HDR. Press again to
disable. Hold the button and rotate the front or rear dial to adjust HDR
settings, including HDR bracketing.
• This role is available for [K Button Function] only.
BKT (N)
Enable bracketing (P. 146). Press once to enable bracketing. Press
again to disable. Hold the button and rotate the front or rear dial to
adjust [Bracketing] settings.
• This role is available for [K Button Function] only.
ISO
Adjust [ISO] settings (P. 75). Hold the control and rotate the front
or rear dial. Alternatively, you can press the button to activate settings
and then rotate the dials. Use the front or rear dial or HI on the
arrow pad to adjust settings.
WB (white balance)
Adjust [WB] settings (P. 94). Hold the control and rotate the front or
rear dial. Alternatively, you can press the button to activate settings
and then rotate the dials. Use the front or rear dial or HI on the
arrow pad to adjust settings.
Multi Function
Confi gure the control for use as a multi-function button (P. 124).
Hold the control and rotate the front or rear dial to choose the
function performed. The selected function can be performed by
pressing the control.
Peaking (PEAK)
Toggle focus peaking on or off (P. 215). Press the control once to
turn peaking on and again to turn it off. When peaking is on, peaking
options (color, amount) can be displayed by pressing the INFO
button.
V
Level Disp
(R)
Display the digital level gauge. The exposure bar display in the
viewfi nder functions as a level gauge. Press the control again to exit.
This option takes effect when [Style 1] or [Style 2] is selected for
[EVF Style] (P. 240) in G Custom Menu a.
u View
Selection
(display selection)
Switch between viewfi nder photography and live view. If [Off] is
selected for [EVF Auto Switch] (P. 196), the display will switch
between the viewfi nder and the monitor. Press and hold the control to
display [EVF Auto Switch] options.
S-OVF (n)
Enable [S-OVF] (P. 197). Press once to turn OVF simulation on.
Press again to turn it off.
• This role is available for [K Button Function] only.
AF Limiter
(AFLimit)
Enable the AF limiter (P. 183). Press once to enable [AF Limiter].
Press again to disable. Hold the button and rotate the front or rear
dial to choose from three stored settings.
• This role is available for [K Button Function] only.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
