Olympus E-M1 Mark III User Manual

121 EN
Shooting
2
Role Function
Preset MF (PreMF)
Toggle [AF Mode] > [Preset MF] on or off (P. 64). Press the control
once to enable preset MF and again to restore the previous focus
mode. Alternatively, you can choose the [AF Mode] by holding the
control and rotating a dial.
This option will have no effect during still photography if [mode2] is
selected for [K Fn Lever Function] (P. 219).
It will likewise have no effect during movie recording if [mode2] is
selected for [n Fn Lever Function] (P. 163).
Lens Info Settings
(sLens)
Recall previously-saved lens data (P. 239). Recall saved data for the
current lens after changing lenses or the like.
IS Mode (IS)
Toggle [Image Stabilizer] on or off (P. 97). Press once to select
[Off] and again to turn image stabilization on. Hold the control and
rotate the front or rear dial to access [Image Stabilizer] options.
Flicker Scan
(P)
Adjust settings for [Flicker Scan] (P. 166, 234). Press the control
to select [On]. You can adjust shutter speed for best results while
viewing banding in the display. Press the control again to display
shooting information and access other settings. Press and hold the
control to select [Off] for [Flicker Scan].
G Lock (touch
control lock)
Lock touch controls. Press and hold the button once to lock touch
controls and again to unlock.
• This function can be assigned to the I and G buttons only. You
must fi rst set [d] to [Direct Function].
Electronic Zoom
(X)
Zoom power zoom lenses in or out. After pressing the control, use the
arrow pad to zoom in or out. Use For I on the arrow pad to zoom
in and G or H to zoom out.
• This function can be assigned to the I and G buttons only. You
must fi rst set [d] to [Direct Function].
Flash Mode (#)
Adjust fl ash settings (P. 86). Press once to display fl ash options
and again select the highlighted option and exit. Highlight settings
using the front or rear dial or HI on the arrow pad.
• This function can be assigned to the I and G buttons only. You
must fi rst set [d] to [Direct Function].
• This role is available for [K Button Function] only.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
