Olympus E-M1 Mark III User Manual

122 EN
Shooting
2
Role Function
j/Y (sequential
shooting/self-timer)
Choose a drive (sequential shooting/self-timer) mode (P. 78).
Press the button to display drive mode options and then choose a
mode using the front or rear dial or the HI buttons on the arrow
pad.
• This function can be assigned to the I and G buttons only. You
must fi rst set [d] to [Direct Function].
• This role is available for [K Button Function] only.
Live ND Shooting
(O)
Enable the live ND fi lter (P. 159). Press once to enable [Live ND
Shooting]. Press again to disable. Hold the button and rotate the front
or rear dial to adjust [Live ND Shooting] settings.
• This role is available for [K Button Function] only.
I Face Selection
(E)
Select the face used for focus when the camera detects multiple
portrait subjects. Pressing the button selects the face closest to the
current AF target. If q (all targets) is selected for AF-target mode,
pressing the button will instead select the face closest to the center
of the frame. To focus on a different face, hold the button and rotate
the front or rear dial. This option can also be used during movie
recording.
I Face Priority
(I)
Pressing the button when an option other than [Face Priority Off] is
selected for [I Face Priority] (P. 92) selects [Face Priority Off]; to
restore the previous setting, press the button again. To change the
option displayed in the [I Face Priority] menu, hold the button and
rotate the front or rear dial.
Live View Boost
(G)
Pressing the button when [Off] is selected for [Live View Boost]
(P. 188) selects [On1]. If an option other than [Off] is selected,
pressing the button selects [Off]; to restore the previous setting, press
the button again. To choose an option for [Live View Boost], hold the
control and rotate the front or rear dial.
• This role is available for [K Button Function] only.
Focus Ring Lock
(B)
Press the control once to disable, and again to enable, the lens
focus ring. This option is available when [S-AFb], [C-AFb], [MF],
[C-AF+TRb], [PreMF], or [FAFb] is selected for [AF Mode].
The b portion of the AF mode indicator is displayed gray while the
ring is disabled.
In the case of lenses equipped with an MF (manual focus) clutch,
pressing the button has no effect when the focus ring is in the MF
position (closer to the camera body).
Focus ring lock ends when you perform an operation such as turning
the camera off or attaching a different lens.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
