Olympus E-M1 Mark III User Manual

164 EN
Menu functions (Video menu)
4
Option Description
g
n Display Settings
Adjust display settings for movie mode. —
n Control Settings
Choose whether live controls (P. 225) and the live
super control panel (P. 88) are displayed in movie
mode. For setting not to display, select the item and
press the Q button to clear the check mark.
—
n Info Settings
Choose the information displayed during recording in
movie mode. For setting not to display, select the item
and press the Q button to clear the check mark.
—
Time Code Settings
Choose how time codes are recorded in movie mode.
Set [Time Code Mode] to [Drop Frame] to record time
codes corrected for errors with respect to recording time,
and to [Non-DF] (no drop frame) to record uncorrected
time codes.
Set [Count Up] to [Rec Run] to run time codes during
recording only, and to [Free Run] to run time codes even
while recording is stopped, including when the camera
is turned off.
In [Starting Time], set a starting time for the time code.
Set [Current Time] to set the time code for the current
frame to 00. To set to 00:00:00:00, select [Reset]. You
can also set time codes using [Manual Input].
—
8 Display Pattern
Choose whether the battery level is displayed as a
percentage (“%”) or as minutes remaining (“min”) in
movie mode and during movie recording.
—
a View Assist
The display can be adjusted for ease of viewing when a
movie-only picture mode option ([k Flat] or [l OM-
Log400]) is selected. Select [On] to adjust the display
hues for ease of viewing.
—
Movie R
Audio will not be recorded in a movie when set to [Off]. 169
n HDMI Output
Adjust output settings for movies recorded with the
camera connected with an external device via HDMI.
—
Output Mode Choose the video output mode. When set to [Monitor
Mode], image and camera information are output. The
camera information is not displayed on the camera
screen.
When set to [Record Mode], only image is output. The
camera information is displayed on the camera screen.
—
REC Bit If set to [On], the REC trigger is sent from the camera to
the connected external device.
—
Time Code If set to [On], the time code is sent from the camera to
the connected external device.
• The recording by the external device that uses the
time code as the REC trigger may be stopped in the
following cases.
- When recording an ART movie, etc., under heavy
processing load
- When switching the display between the monitor
and viewfi nder
—

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
