O PERATION : C ONFIGURATION M ODE
part
3
83
Command Formats cont.
COMM.PARAMETERS.210 = 000 300 BAUD COMM. PARAMETERS.43 = 00 No Parity
001 600 01 Odd
010 1200 10 Even
011 2400 11 N/A
100 4800
101 9600
110 19200
COMM. PARAMETERS.5 = 0 7 Bit Data COMM. PARAMETERS.6 = 0 1 Stop Bit
1 8 Bit Data 1 2 Stop Bit
Example: Set Baud 9600, Odd, 7 Bit, 1 Stop. The command data is 00001101Bin = 0DHex. Send *W100D.
BUSFORMAT.0 = N/A BUS FORMAT.1 = 0 No LF BUS FORMAT.2 = 0 No Echo
1 LF 1 Echo
BUSFORMAT.3 = 0 RS-232 BUS FORMAT.4 = 0 Continuous BUS FORMAT.5 =0CR
1 RS-485 1 Command 1 Space
Example: Set Space, Continuous, RS-232, Echo, Line Feed, N/A. The command data is 00000110Bin = 06Hex. Send *W1F06.
