OMEM710 Hardware Manual 2v11
60
The User1 table uses a raw source (scaled to 0-255) for the upper (input) axis of the table to drive a
PWM output, the duty cycle of which is defined on the lower axis of the table.
The raw input is selected by option User1 source. Useful selectable sources are;
Air temperature
Baro pressure
Battery voltage
Coolant temperature
Engine Speed
Injector duty
Knock
Lambda
MAP
Throttle position
The PWM output number used is defined by the option User1 PWM out.
