29.3 Component Pin-outs
Throttle Position Sensors (TPS)
Omex Part Number
Description
Pins
Omex Wire Colour
OMEM2001
General
Purpose
1 Signal (green)
2 +5v (red)
3 Sensor Earth
(Black)
Orange
Pink
Grey
OMEM2005
Jenvey
1 Signal (red)
2 +5v (Green)
3 Sensor Earth
(yellow)
Orange
Pink
Grey
MAP Sensors
Omex Part Number
Description
Pins
Omex Wire Colour
OMEM2001
1 Bar
1 Signal
2 Sensor Earth
3 +5v
Grey
Pink
OMEM2002
2 Bar
OMEM2003
3 Bar
Coils
Omex Part Number
Description
Pins
Omex Wire Colour
Sagem / Valio Coil
OMEM3501
4 Cyl DIS
1 Ign 1
2 Ign 2
3 +12v Supply
4 n/f
Switched
Ford Coil
OMEM3503
4 Cyl DIS 3 pin
1 Ign 1
2 +12v
3 Ign 2
Switched
Temperature Sensors
Omex Part Number
Description
Pins
Omex Wire Colour
OMEM2200
Coolant Temp
(CTS)
1 Sensor Out
2 Sensor Earth
White / Violet
Grey
OMEM2201
Air Temp
(ATS)
1 Sensor Out
2 Sensor Earth
White / Green
Grey
Crank Position Sensors (CPS)
Omex Part Number
Description
Pins
Omex Wire Colour
OMEM2401
2 hole mounting
1 Sensor Out
2 Sensor Earth
Black screened red
Black screened blue
Oxygen (Lambda) Sensors
Omex Part Number
Description
Pins
Omex Wire Colour
OMEM2300
4 wire
Sensor Out (Black)
Sensor Earth (Grey)
Heater (White)
Heater (White)
Grey
+12v Switched
Earth
