Trim Press Device
General Description
Cutting press or trim press is a device that cut the peripheral of the pieces. It is made out of two
mobile tables that are going up and down between guides. The table’s movement is provided by a
system of servo motors mounted on the upper and lower table.
Schematic
Upper motor.
Upper table position
adjustment.
Upper toggle system.
Upper die cutting
adjustment with hot
plate.
Upper cutting table
Lower cutting table
Lower motor.
Lower toggle system.
