MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 74 a 179
Pneumatic connection
Pneumatic connection is made with tubes with minimal 1” diameter. The air supply pressure must
be 6 bar (or 90 PSI) minimum and 8 bar (or 120 PSI) maximum.
Be sure that the compressor is supplying air with low humidity percentage to avoid emptying
frequently the filter of the FRL from water accumulation.
A malfunction of the filter, because of too much water in the plant air system, could result in an
oxidation of internal components in the machine.
Main air supply connection.
Main air supply pressure gauge.
