OMG MF 64 - Schematic

MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 95 a 179
Schematic
1. Left blade
2. Right blade
3. Cartridge heater
4. Pneumatic cylinder
5. Pneumatic cylinder spacer
6. Film sliding plate
7. Film sliding plate adjustment knobs
8. Thermocouple
4
6
2
5
8
7
3
1
