MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 65 a 179
Note: If a cable with neutral (4 pins) is needed, it must be connected on the left side of the main
switch (the main switch will have 4 connectors).
Connect the cables, on the appropriate terminal, following these instructions:
3 cables for phases (see electrical schematic provided with manual).
1 cable for neutral
Connect ground cable
on the copper bus bar.
