OMG MF 64 - Adjustments & Setup

MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 147 a 179
Adjustments & Setup
Lift and slide the tool into the rails as shown on the pictures.
Center the cutting tool and tight it with the set screws provided with the machine.
Slide here
Cutting die tool
Screws on the rails of upper and
lower platen are used to hold cutting
die in position.
