OMG MF 64 - Water Scheme; Cooling System

MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 70 a 179
The water dispenser is managed as follows:
8. Cooling water Inlet connection
9. Cooling water Outlet connection
10. Thermoregulation water Inlet connection
11. Thermoregulation Water Outlet Connection
12. Delivery of cooling water to the chain guides
13. Return of cooling water from the chain guides
14. Cooling water delivery to the mold
15. Return of cooling water from the mold
16. Cooling water delivery to the die (cut)
17. Return of cooling water from the die (cut)
Water scheme
See attached scheme
Cooling System
Thermoforming equipment is generating a lot of heat. For this reason, it is mandatory to use a
cooling system to regularize temperature in different sections of the machine.
4
5
6
2
3
1
10
9
8
7
7
