MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 162 a 179
When the stacking counter movement is completed, it is indispensable to extract the piles from the
conveyor. For this purpose, there is a system that pushes the piles out of the stacker, and pushes
them on conveyor located at the side-exit of the machine.
discharge conveyor
movement left.
When the counter
finishes, the
extractor empty the
stacker magazine.
Lateral conveyor position adjustment
