MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 45 a 179
The water dispenser is managed as follows:
1. Chiller water Inlet connection
2. Chiller water Outlet connection
3. Thermoregulator water Inlet connection
4. Thermoregulator Water Outlet Connection
5. Electrical valve for Delivery of cooling water to the chain rails
6. Electrical valve for Delivery of cooling water from the mold
7. Electrical valve for Delivery of cooling water from the die plate (cut)
