MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 97 a 179
There is also a pneumatic regulator "9" which allows the adjustment of the up and down speed of
the blades on the non-woven material
Turning the knobs "10" clockwise and counterclockwise respectively reduces or increases the air
flow to the cylinders that control the blades, thus speeding up or slowing down their stroke.
Make sure that there are no residues of material and foreign bodies
inside the device that could damage the components during the
adjustment procedure.
