CMC 356 Reference Manual
60
6.4 Inputs
6.4.1 Binary Inputs
Note: If option ELT-1 is installed, only the general binary input data given in
the following Table 6-16 are valid. For detailed information about the option
ELT-1, please refer to section 6.11, "Option ELT-1" on page 71.
Table 6-16:
General data of
binary inputs
General Data of Binary Inputs 1…10
Number of binary inputs 10
Trigger criteria Potential-free or DC-voltage compared to
threshold voltage
Reaction time Max. 220
µ
s
Sampling frequency 10 kHz
Time resolution 100
µ
s
Max. measuring time Unlimited
Debounce time 0…25 ms (refer to page 62)
Deglitch time 0…25 ms (refer to page 62)
Counting function
counter frequency
pulse width
3 kHz (per input)
>150
µ
s (for high and low signals)
Configuration Binary inputs can be configured. Refer to the
OMICRON Test Universe Help.
Connection 4 mm/0.16 " banana sockets on the front
panel
Insulation 5 galvanic insulated binary groups with each
2 inputs having its own GND.
Operation insulation to the power outputs, DC
inputs and between galvanically separated
groups.
Reinforced insulation from all SELV
interfaces and from power supply.
