CMC 356 Reference Manual
94
6.12 Option LLO-2 (Low Level Outputs)
The LLO-2 option ("LL out 7 - 12") represents an additional SELV
(SELV = S
afety Extra Low Voltage) interface connector holding two
independent generator triples. These six high accuracy analog signal
sources can serve to either control an external amplifier or to directly
provide small signal outputs.
The outputs 7-12 extend the low level outputs 1-6 ("LL out 1-6") by two more
independent generator triples. Outputs 7-12 are technically identical to
outputs 1-6.
For more information please refer section 6.3.5, "Low Level Outputs "LL out"
for External Amplifiers" on page 54.
