Omicron CMC 356 User Manual

Technical Data
77
Table 6-31:
Data for potential-sensing
operation
Table 6-32:
Data for potential-free
operation
6.11.6 Multimeter Mode
This operating mode is designed for measuring steady-state signals (e.g.,
also non-sinusoidal shaped signals). Measurements such as rms values,
phase angle, frequency, etc. can be performed.
The input signals are processed in real time without delay.
Data for Potential-Sensing Operation
Threshold voltage data per input
range
Setting range Resolution
100 mV
1V
10 V
100 V
600 V
±100mV
±1V
±10V
±100V
±600V
2mV
20 mV
200 mV
2V
20 V
Max. input voltage CAT II / 600 V
rms
(850 V
pk
)
CAT III/ / 300 V
rms
CAT IV / 150 V
rms
Threshold voltage accuracy
1
per range:
100 mV, 1 V, 10 V, 100 V,
600 V
1
Valid for positive voltage signal edge; percentage is shown in respect to each range’s
full-scale.
Error:
typical < 2 %, guaranteed < 4 %
typical < 5 %, guaranteed < 10 %
Threshold voltage hysteresis:
100mV, 1V, 10V, 100V,
600 V
Typical:
3.5% of range + 1.3% of setting
5.8% of range + 1.3% of setting
Input impedance
500 k
Ω (|| 50 pF)
Data for Potential-Free Operation
1
1
Refer to figure 5-2, "Simplified circuit diagrams of binary inputs and outputs (CMC 356
standard, without option ELT-1 installed)" on page 30.
Trigger criteria
Logical 0: R > 80 k
Ω
Logical 1: R < 40 kΩ
Input impedance
162 k
Ω (|| 50 pF)
