6.3.3 Voltage Outputs
Table 6-7:
CMC 356 voltage outputs
Footnotes:
1.a) V
L4
(t) automatically
calculated:
V
L4
=(V
L1
+ V
L2
+ V
L3
)*C
C: configurable constant
from –4 to +4.
b) V
L4
can be configured
by software in frequency,
phase, and amplitude.
2. Guaranteed data for
ohmic loads, (PF=1).
Refer to the
accompanying figure of
the output power
curves.
Refer to section 6.3.4,
"Operational Limits in
Conjunction with Mains
Supply" on page 53.
3.Data for three-phase
systems are valid for
symmetric conditions
(0 °, 120 °, 240 °).
4.Data for four-phase
systems are valid for
symmetric conditions
(0 °, 90 °, 180 °, 270 °).
5.rd. = reading;
rg. = range, whereat
n % of rg. means: n % of
upper range value.
6.Valid for sinusoidal
signals at 50/60 Hz.
7. 20 kHz measurement
bandwidth, nominal
value, and nominal load.
8. If you purchased the
option FL-6, the
maximum output
frequency is constrained
to 599 Hz.
4 Voltage Outputs
Output voltages
3-phase AC (L-N)
4-phase AC (L-N)
1
1-phase AC (L-N)
1-phase AC (L-L)
DC (L-N)
3 x 0...300V
4 x 0...300V
1 x 0...300V
1 x 0...600V
4 x 0 ... ± 300 V
Output power
2
Typical Guaranteed
3-phase AC
3
4-phase AC
4
1-phase AC (L-N)
1-phase AC (L-L)
DC (L-N)
3 x 100 VA at 100 ... 300 V
4 x 75 VA at 100 ... 300 V
1 x 200 VA at 100 ... 300 V
1 x 275 VA at 200 ... 600 V
1 x 420 W at 300 VDC
3 x 85 VA at 85 ... 300 V
4 x 50 VA at 85 ... 300 V
1x150VA at 75...300V
1 x 250 VA at 200... 600 V
1 x 360 W at 300 VDC
Accuracy
Error < 0.03 % of rd.
5
+ 0.01 % of rg.
Error < 0.08 % of rd.
+ 0.02 % of rg.
Harmonic distortion
(THD+N)
6, 7
0.015 % < 0.05 %
Phase error
6
Typical 0.02 ° Guaranteed < 0.1 °
DC offset voltage < 20 mV < 100 mV
Voltage ranges Range I: 0 ... 150 V
Range II: 0 ... 300 V
Resolution Range I: 5 mV
Range II: 10 mV
Frequency ranges
8
Sinusoidal signals
harmonics/interharm.
9
transient signals
10 … 1000 Hz
10 … 3000 Hz
DC … 3.1 kHz
Short-circuit protect. Unlimited for L - N
Connection 4 mm/0.16 " banana connectors; amplifier
connection socket V
L1
-V
L3
Insulation Reinforced insulation of power supply and all SELV
interfaces
9
Signals above 1 kHz are only supported in selected software modules and are only available
on the voltage outputs and the low level outputs.
