Table 6-6:
Typical duty cycles for
operation at ambient
temperature of 23 °C
6 x 32 A (L-N) 3 x 64 A (L-N)
I
[A]
P
[W]
duty
cycle
t1
[min]
ton
[s]
toff
[s]
I
[A]
P
[W]
duty
cycle
t1
[min]
ton
[s]
toff
[s]
0 ... 25 0 ... 1200 100% > 30 > 1800 - 0 ... 50 0 ... 1200 100% > 30 > 1800 -
26 1400 80% 7.5 80 20 52 1400 80% 7.5 80 20
29 1300 75% 6.0 60 20 58 1300 75% 6.0 60 20
32 1200 71% 3.5 50 20 64 1200 71% 3.5 50 20
1 x 128 A (LL-LN)
I
[A]
P
[W]
duty
cycle
t1 [min] ton
[s]
toff [s]
0 .... 80 0 ... 700 100% > 30.0 > 1800 0
100 450 60% 4.9 30 20
120 300 43% 2.6 15 20
128 200 38% 2.0 12 20
