6.11.7.2 Accuracy of Amplitude Measurement
The measurement values are given as effective values (rms).
The permitted input frequency range for the fundamental wave depends on
the specified sampling rate:
Table 6-47:
Sampling rate and input
frequency range
Valid for fundamental and harmonic waves in specified frequency range; accuracy
refers to full scale.
Table 6-48:
Sampling rate 28.44 kHz,
measurement range
600 V, 100 V, 10 V, 1 V
Table 6-49:
Sampling rate 28.44 kHz,
measurement range
100 mV
Table 6-50:
Sampling rate
9.48 kHz
3.16 kHz,
measurement range
600 V, 100 V, 10 V, 1 V
Sampling rate Input frequency range
28.44 kHz 100 Hz (= fmin) ... 3200 Hz
9.48 kHz 30 Hz (= fmin) ... 1000 Hz
3.6 kHz 10 Hz (= fmin) ... 350 Hz
Frequency range Accuracy
Typical Guaranteed
fmin ... 1 kHz ± 0.1 % ± 0.3 %
fmin ... 10 kHz + 0.1 % / - 0.7 % ± 1.1 %
Frequency range Accuracy
Typical Guaranteed
fmin ... 1 kHz ± 0.2 % ± 0.5 %
fmin ... 10 kHz + 0.2 % / - 1.0 % ± 2.0 %
Frequency range Accuracy
Typical Guaranteed
fmin ... 100 Hz ± 0.1 % ± 0.3 %
fmin ... 1 kHz + 0.1 % / - 0.5 % ± 0.8 %
fmin ... 4 kHz
(sampling rate = 9.48 kHz)
+ 0.1 % / - 0.8 % ±1.2 %
fmin ... 1.4 kHz
(sampling rate = 3.16 kHz)
+ 0.1 % / - 0.8 % ±1.2 %
