Technical Data
43
6.3 Outputs
For block diagrams of the available generator outputs, please refer to
section 4.1, "Block Diagram" on page 22.
Table 6-3:
Analog current, voltage,
and LL outputs.
All voltages and current generators can independently be configured with
respect to amplitude, phase angle, and frequency.
All outputs are monitored. Overload conditions result in a message
displayed on the PC.
General Generator Outputs Data
(analog current and voltage outputs, outputs "LL out")
Frequency ranges
1
sinusoidal signals
2
harmonics / interharmonics
3
transient signals
1
If you purchased the option FL-6, the maximum output frequency is constrained to 599 Hz.
2
Amplitude derating for current outputs at frequencies above 380 Hz.
3
Signals above 1 kHz are only supported in selected Test Universe modules and are only
available on the voltage outputs and the low level outputs.
10 … 1000 Hz
10 … 3000 Hz
DC … 3.1 kHz
Frequency resolution < 5 µHz
Frequency accuracy ± 0.5 ppm
Frequency drift ± 1 ppm
Bandwidth (–3 dB) 3.1 kHz
Phase range ϕ - 360° to + 360°
Phase resolution 0.001°
Synchronized operation Generator outputs can be synchronized
to a reference input signal on
binary/analog input 10 (range:
15 … 70 Hz).
Temperature drift 0.0025 %/°C
