5-180
5-14 Other Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
5
Functions
The following table gives the differences in the setting ranges and default
settings for parameters in Normal Mode with a Heavy Load Rating (CT) and
High-frequency Mode.
Parameter
No.
Function name
Normal Mode with a Heavy Load
Rating (CT)
High-frequency Mode
Setting range Default Setting range Default
F002 Acceleration Time
Setting 1
0.01 to 3,600.00 [s] 10.00 0.01 to 3,600.00 [s] 30.00
F202 Acceleration Time
Setting 2
0.01 to 3,600.00 [s] 10.00
0.01 to 3,600.00 [s] 30.00
F003 Deceleration Time
Setting 1
0.01 to 3,600.00 [s] 10.00
0.01 to 3,600.00 [s] 30.00
F203 Deceleration Time
Setting 2
0.01 to 3,600.00 [s] 10.00
0.01 to 3,600.00 [s] 30.00
A003 Base Frequency 1 30.0 to Maximum Frequency
1 (A004) [Hz]
60.0 30.0 to Maximum Frequency
1 (A004) [Hz]
1000.0
A203 Base Frequency 2 30.0 to Maximum Frequency
2 (A204) [Hz]
60.0 30.0 to Maximum Frequency
2 (A204) [Hz]
1000.0
A004 Maximum
Frequency 1
Base Frequency 1 (A003) to
400.0 [Hz]
60.0 Base Frequency 1 (A003) to
1,000.0 [Hz]
1000.0
A204 Maximum
Frequency 2
Base Frequency 2 (A203) to
400.0 [Hz]
60.0 Base Frequency 2 (A203) to
1000.0 [Hz]
1000.0
A011 FV Start Frequency 0.00 to 400.00 [Hz] 0.00 0.00 to 1,000.00 [Hz]
0.00
A012 FV End Frequency 0.00 to 400.00 [Hz] 0.00 0.00 to 1,000.00 [Hz]
0.00
A044 Control Method 1 00: VC
01: VP 1.7th power <VC, if low
speed>
02: Free V/f setting
03: Sensorless vector control
00 00: VC
01: VP 1.7th power <VC, if
low speed>
02: Free V/f setting
00
A244 Control Method 2 00: VC
01: VP 1.7th power <VC, if low
speed>
02: Free V/f setting
03: Sensorless vector control
00 00: VC
01: VP 1.7th power <VC, if
low speed>
02: Free V/f setting
00
A059 DC Injection
Braking Carrier
Frequency
2.0 to 15.0 [kHz] 5.0 2.0 to 10.0 [kHz]
5.0
A063 Jump Frequency 1 0.00 to 400.00 [Hz] 0.00 0.00 to 1,000.00 [Hz]
0.00
A064 Jump Frequency
Width 1
0.00 to 10.00 [Hz] 0.50 0.00 to 100.00 [Hz]
0.50
A065 Jump Frequency 2 0.00 to 400.00 [Hz] 0.00 0.00 to 1,000.00 [Hz]
0.00
A066 Jump Frequency
Width 2
0.00 to 10.00 [Hz] 0.50 0.00 to 100.00 [Hz]
0.50
A067 Jump Frequency 3 0.00 to 400.00 [Hz] 0.00 0.00 to 1,000.00 [Hz]
0.00
A068 Jump Frequency
Width 3
0.00 to 10.00 [Hz] 0.50 0.00 to 100.00 [Hz]
0.50
A069 Acceleration Stop
Frequency
0.00 to 400.00 [Hz] 0.00 0.00 to 1,000.00 [Hz]
0.00
A092 1st Acceleration
Time 2
0.01 to 3,600.00 [s] 10.00
0.01 to 3,600.00 [s] 15.00
A292 2nd Acceleration
Time 2
0.01 to 3,600.00 [s] 10.00
0.01 to 3,600.00 [s] 15.00
