A
A-4 CP1L Programming Examples
SYSMAC CP1L Getting Started Guide 131
Appendix
3. Double-click [D] in the data area workspace.
The PLC data table will be displayed.
4. Input the values for the DM addresses.
5. Click [Save in Project].
The settings will be saved.
6. Transfer the data from the computer to CP1L.
1)Confirm that the computer is online with CP1L.
2)Select [Online] - [Transfer to PLC] from the menu.
The Transfer to PLC dialog box will be displayed.
3)Select the area and its region for the transfer. Click [Transfer to PLC].
The data will be transferred.
W07E-EN-02+CP1L+GettingStartedGuide.book Seite 131 Montag, 15. September 2008 11:15 11
To Next Page
