A
A-4 CP1L Programming Examples
130 SYSMAC CP1L Getting Started Guide
Appendix
zDM Area Setup
The following values are set into the DM area as BCD.
1. Open the CX-Programmer main window.
2. Double-click [Memory] in the project tree.
The Memory window will be displayed.
Channel Value Content
D0 3000 30min 00sec
D1 0017 17hr
D2 0000 -
D10 3000 30min 00sec
D11 0020 20hr
D12 0000 -
D20 0000 00min 00sec
D21 0010 10hr
D22 0000 -
D30 1500 15min 00sec
D31 0021 21hr
D32 0000 -
W07E-EN-02+CP1L+GettingStartedGuide.book Seite 130 Montag, 15. September 2008 11:15 11
