131
Allocations to Slave Units Section 5-2
Note Bits 0, 1, and 3 output a logical OR of the status of all Slave Units other than
Repeater Units; bits 4 and 5 output an OR of Repeater Unit status only; and
bit 2 outputs an OR of the status of all Slave Units including Repeater Units.
Example: In this example, operation is considered normal when all registered
Slave Units are participating, there are no communications errors at any reg-
istered Slave Units, and remote I/O communications are operating.
05 Repeater Unit
Node Duplicated
Address Error
Flag
OFF: Normal
ON: Error
Note Remote I/O communications will start even if
this flag is ON.
06 All Registered
Slave Units Par-
ticipating Flag
Enabled only in Registration Table Enable Mode, i.e.,
when SW4 (REGS) is turned ON on the Master Unit
when the power is turned ON.
OFF: A Slave Unit is not participating. (Not all Slave
Units in the Registration Table are participating.)
ON: All Slave Units in the Registration Table are par-
ticipating.
Note Turns ON when all Slave Units in the Registra-
tion Table are participating, even if an unregis-
tered Slave Unit is also participating.
Note When the Registered Slave Unit Participation
Standby Mode is enabled, remote I/O commu-
nications will stop while this flag is OFF. They
start when it turns ON.
07 Remote I/O Com-
munications
Started Flag
OFF: Remote I/O communications are stopped.
ON: Remote I/O communications are operating.
08 Ladder Operation
Allowed Flag in
Registration Table
Enabled Mode
OFF: Ladder program operations are not possible.
(The ladder program should not be used in relation to
remote I/O communications.)
ON: Ladder program operations are possible. (The
ladder program can be used in relation to remote I/O
communications.)
Note Flag status is determined by a logical AND
based on bit 0 (no communications error), bit 6
(all registered Slave Units participating), and bit
7 (remote I/O communications operating).
09 Reserved Cannot be used.
10 Registration Table
Mode Flag
OFF: Registration Table Disable Mode. SW4 (REGS)
on the Master Unit was turned OFF when the power
was turned ON, or the Registration Table data is ille-
gal.
ON: Registration Table Enable Mode. SW4 (REGS)
on the Master Unit was turned ON when the power
was turned ON, and the Registration Table data is not
illegal.
11 Reserved Cannot be used.
12 Representative
Warning Status
Flag
Logical OR of the Warning Status Flags for all Slave
Units.
13 Representative
Alarm Status Flag
Logical OR of the Alarm Status Flags for all Slave
Units.
14 Reserved Cannot be used.
15 Reserved Cannot be used.
Bit
address
Name Contents
