Appendix
Cold junction Com-
pensation Method
cjc OFF, ON off, on ON None
MB Command Logic
Switching
rlrv OFF, ON off, on OFF None
PV Change Color colr Orange, Red, Green
Red to Green: When ALM1 is
lit,
Green to Red: When ALM1 is
lit
Red to Green to Red
Within PV stable band:
Green
Outside stable band: Red
Green to Orange to Red
Within PV stable band:
Green
Outside stable band: Green,
Red
Orange to Green to Red
Within PV stable band:
Green
Outside stable band: Green,
Red
org, red,
grn
r-g
g-r
r-g.r
g-o.r
o-g.r
RED None
PV Stable Band pv-b Universal input: 0.1 to 999.9 5.0 °C or °F
(See note
1.)
Analog input: 0.01 to 99.99 5.00 %FS
Alarm 1 ON Delay a1on 0 to 999 (0: ON delay dis-
abled)
0Second
Alarm 2 ON Delay a2on 0 to 999 (0: ON delay dis-
abled)
0Second
Alarm 3 ON Delay a3on 0 to 999 (0: ON delay dis-
abled)
0Second
Alarm 1 OFF Delay a1of 0 to 999 (0: OFF delay dis-
abled)
0Second
Alarm 2 OFF Delay a2of 0 to 999 (0: OFF delay dis-
abled)
0Second
Alarm 3 OFF Delay a3of 0 to 999 (0: OFF delay dis-
abled)
0Second
Input Shift Type istp INS1: Temperature input 1-
point shift
INS2: Temperature input 2-
point shift
ins1, ins2 INS1 None
MV at Stop and Error
Addition
mvst OFF, ON off, on OFF None
Auto/Manual Select
Addition
amad OFF, ON off, on OFF None
RT rt OFF, ON off, on OFF None
HS Alarm Use hsu OFF, ON off, on ON None
HS Alarm Latch hsl OFF, ON off, on OFF None
HS Alarm Hysteresis hsh 0.1 to 50.0 0.1 A
LBA Detection Time lba 0 to 9999 (0: LBA function dis-
abled)
0Second
LBA Level lbal Universal input: 0.1 to 999.9 8.0 °C or °F
(See note
1.)
Analog input: 0.01 to 99.99 10.00 %FS
Parameters Characters Setting (monitor) value Display Default Unit Set value
