119
F3SJ-E/B
User’s Manual
Chapter6 Troubleshooting
Appendix
E
Description Cause and measures
Cap error A cap may be detached. Attach the cap properly.
Communication error
The communication line or other wiring may be broken or short-circuited.
Check the wiring and cables.
A power cable may be detached.
Check connectors of the power cable.
If the wiring is extended with cables other than specified, the cables used for extension may not
have performance equivalent or greater than the specified cables. Use cables with the same
performance or more than the specified cables.
See "Wiring" in Chapter 3.
Safety output error
Safety output lines may be short-circuited to each other or another signal line may be short-
circuited to the safety output line.
Wire the safety output lines properly.
See "Wiring Diagrams" in Chapter 2 or "Wiring" in Chapter 3.
Input wiring error
Combinations of interlock select input line and reset input line may be wrong.
The reset input line may not have been properly wired when a muting key cap was mounted.
Perform correct wiring.
See "Wiring Diagrams" in Chapter 2 or "Wiring" in Chapter 3.
External device monitoring error
Emitter(s) and receiver(s) may be reversely connected to connectors on a controller. Check the
connecting positions with the connectors.
If the external device monitoring input line is short-circuited to the auxiliary output line instead of a
relay, the auxiliary output line may be broken or short-circuited to another line.
Relay may be welded.
Replace the relay.
The relay and external device monitoring input line may not be properly wired.
Check the wiring with the relay.
See "Wiring Diagrams" in Chapter 2 or "Wiring" in Chapter 3.
The relay response time may be exceeding the allowable delay time (0.3 s).
Replace the relay with one that has an appropriate response time.
See "Wiring Diagrams" in Chapter 2 or "Wiring" in Chapter 3.
Internal error
An error may have occurred in the internal circuit.
Replace the F3SJ-E/B.
Configuration error of emitter-
receiver combination
A model name does not match between emitter and receiver. Check that the emitter and receiver
are the same model.
Series connection cables may have been short-circuited, broken or disconnected. Check if series
connection cables are connected properly. Replace a series connection cable if it is broken.
Ambient light error
The receiver may be receiving light emitted from another photoelectric switch or F3SJ-E/B.
See "Mutual Interference Prevention" in Chapter
3.
p.41
To Next Page
