3 Configuration
3 - 70
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
z
DVI-Analog Conversion Cable for Touch Panel Monitor: FH-VMDA
*1. Cable is available in 2 m/5 m/10 m.
z
RS-232C Cable for Touch Panel Monitor: XW2Z-

PP-1
*1. Cable is available in 2 m/5 m/10 m.
z
USB Cable for Touch Panel Monitor: FH-VUAB
*1. Cable is available in 2 m/5 m.
17-pin DVI connector
15-pin D-SUB connector
45±5
L
*1
45±5
10±2
L
*1
40
9-pin D-SUB connector 9-pin D-SUB connector
11.5 max.
45±5
45±5
12±0.25
L
*1
12±0.25
4-pin USB B type connector
4-pin USB A type connector
15
8 max.
10.5 max.
10±2

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
