Precautions for Correct Use
20
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
• Do not install the product in a cabinet containing high-voltage equipment.
• Do not install the Sensor Controller within 200 mm of power cables.
• Touching Signal Lines
When touching a terminal part or a signal wire in a connector, take anti-static measures using a wrist
strap or another device to prevent damage from static electricity.
• Handling a USB Memory/SD memory card
For more details, refer to Using External Memory Device in the Vision System FH/FZ5 Series User’s
Manual (Cat. No. Z365).
• Do not insert an SD memory card in the reverse orientation, at an angle, or in a twisting manner.
• Before removing a USB memory device or SD memory card, make sure that data is not being read or
written to them.
For a USB memory device, the memory device's LED flashes or lights while data is being read or
written, so make sure that it is turned OFF before removing the memory.
For SD memory card, the SD BUSY LED flashes or lights while data is being read or written, so make
sure that it is turned OFF before removing the memory.
• Turning OFF the Power Source
When a message is displayed indicating that a task is in progress, do not turn OFF the power.
Doing so causes the data in the memory to be corrupted, resulting in the product not operating prop-
erly upon the next start-up.
• When turns OFF, conform the followings proceedings have completed. and then operate again.
• When saves using Sensor Controller:
Confirm the save processing is completed and next operation is possible.
• When saves using communication command:
Intended command is completed. BUSY signal is turned OFF.
• Setting of Power Source
The power source need to be supplied from DC power source apparatus which is taken a save
ultra-low voltage circuit: to protect high voltage.
• Turn OFF the power and ensure the safety before maintenance.
• Clean the lens with a lens-cleaning cloth or air brush.
• Lightly wipe off dirt with a soft cloth.
• Dirt on the image element must be removed using an air brush.
• Do not use thinners or benzene.
• To ensure safe access for operation and maintenance, separate the Sensor Controller as much as
possible from high-voltage equipment and power machinery.
• After confirming that this product is started up, communicate with the high-order device.
When this product has started up, an indefinite signal may be output from the high-order interface.
To avoid this problem, clear the receiving buffer of your device at initial operations.
Noise Resistance
Component Installation and Handling
Maintenance
Communication with High-order Device
To Next Page
