Omron fh series Hardware Manual

6 I/O Interface
6 - 30
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Pin Layout
No. Signal name
Wire
color
Mark (red) Function
A1 Vacant Orange Ŷ
A2 Vacant Gray Ŷ
A3 Vacant White Ŷ
A4 Vacant Yellow Ŷ
A5 Vacant Pink Ŷ
A6 DI1 Orange ŶŶ Command inputs
A7 DI3 Gray ŶŶ
A8 DI5 White ŶŶ
A9 DI7 Yellow ŶŶ
A10 STGOUT1 Pink ŶŶ
Strobe trigger output
*1
A11 STGOUT3 Orange ŶŶŶ
Strobe trigger output
*1
A12 ERROR Gray ŶŶŶ ON when there is an error.
A13 Vacant White ŶŶŶ
A14 Vacant Yellow ŶŶŶ
A15 Vacant Pink ŶŶŶ
A16 Vacant Orange ŶŶŶŶ
A17 Vacant Gray ŶŶŶŶ
A18 DO1 White ŶŶŶŶ Data output
A19 DO3 Yellow ŶŶŶŶ
A20 DO5 Pink ŶŶŶŶ
A21 DO7 Orange
ŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶ
A22 DO9 Gray ŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶ
A23 DO11 White ŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶ
A24 DO13 Yellow ŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶ
A25 Vacant Pink ŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶŶ
B1 RESET Orange Ŷ Controller restart
B2 Vacant Gray Ŷ
B3 Vacant White Ŷ
B4 STEP0 Yellow Ŷ Measurement trigger input
B5 DSA0 Pink Ŷ Data send request signal
B6 DI0 Orange ŶŶ Command inputs
B7 DI2 Gray ŶŶ
B8 DI4 White ŶŶ
B9 DI6 Yellow ŶŶ
B10 STGOUT0 Pink ŶŶ
Strobe trigger output
*1
B11 STGOUT2 Orange ŶŶŶ
Strobe trigger output
*1
B12 RUN Gray ŶŶŶ ON while the layout turned on output setting is dis-
played ON during processing
B13 BUSY0 White ŶŶŶ ON during processing
B14 GATE0 Yellow ŶŶŶ ON for the set output time
B15 OR0 Pink ŶŶŶ Overall judgement result
B16 READY0 Orange ŶŶŶŶ ON when image input is allowed
