Omron fh series Hardware Manual

3 - 3
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-1 Sensor Controller
3
3-1-1 FH-1000/FH-3000 Series
External
Interface
Serial Communication
RS-232C × 1
Ethernet
Communi-
cation
Protocol Non-procedure (TCP/UDP)
I/F
1000BASE-T × 1 1000BASE-T × 2 1000BASE-T × 1 1000BASE-T × 2
EtherNet/IP Communica-
tion
Ethernet port (transmission rate: 1Gbps)
EtherCAT Communication Yes (slave)
Parallel I/O • 12 inputs/31 outputs:
• Use 1 Line.
• Operation mode: Except Multi-line random-trigger mode.
• 17 inputs/37 outputs:
• Use 2 Lines.
• Operation mode: Multi-line random-trigger mode.
• 14 inputs/29 outputs:
• Use 3 to 4 Lines.
• Operation mode: Multi-line random-trigger mode.
• 19 inputs/34 outputs:
• Use 5 to 8 Lines.
• Operation mode: Multi-line random-trigger mode.
Encoder Interface Input voltage: 5 V ± 5%
Signal: RS-422A LineDriver Level
Phase A/B/Z: 1 MHz
Monitor Interface DVI-I output (Analog RGB & DVI-D single link) × 1
USB I/F USB2.0 host × 4 (BUS Power: Port5 V/0.5 A)
SD Card I/F SDHC × 1
Indicator
Lamps
Main POWER: Green
ERROR: Red
RUN: Green
ACCESS: Yellow
Ethernet NET RUN:
Green
NET LINK
ACT: Yellow
NET RUN1: Green
NET LINK ACK1: Yellow
NET RUN2: Green
NET LINK ACK2: Yellow
NET RUN:
Green
NET LINK
ACT: Yellow
NET RUN1: Green
NET LINK ACK1: Yellow
NET RUN2: Green
NET LINK ACK2: Yellow
SD Card SD POWER: Green
SD BUSY: Yellow
EtherCAT EtherCAT RUN LED: Green
EtherCAT LINK/ACT IN LED: Green
EtherCAT LINK/ACT OUT LED: Green
EtherCAT ERR LED: Red
Power-supply voltage 20.4 VDC to 26.4 VDC
Sensor Controller Series FH-3000 series FH-1000 series
Type High-speed Controller (4 cores) Standard Controller (2 cores)
Sensor Controller Model FH-3050 FH-3050-10 FH-3050-20 FH-1050 FH-1050-10 FH-1050-20

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
