3 Configuration
3 - 4
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
*1. When the 12 megapixels camera: Max. 4 cameras are connectable.
When use except 12 megapixels cameras: Max. 8 cameras are connectable.
*2. Existing third class grounding
Current
consump-
tion
When con-
nected to a
Controller
Connected to
2 cameras
5.0 A max. 5.4 A max. 6.4 A max. 4.7 A max. 5.0 A max. 5.9 A max.
Connected to
4 cameras
---
7.0 A max. 8.1 A max.
---
6.5 A max. 7.5 A max.
Connected to
8 cameras
--- ---
11.5 A
max.
--- ---
10.9 A
max.
When not
connected
to Control-
ler
Connected to
2 cameras
4.1 A max. 4.2 A max. 5.2 A max. 3.6 A max. 3.7 A max. 4.5 A max.
Connected to
4 cameras
---
4.8 A max. 5.6 A max.
---
4.3 A max. 5.0 A max.
Connected to
8 cameras
--- ---
6.8 A max.
--- ---
6.2 A max.
Built-in FAN Yes
Usage
Environ-
ment
Ambient temperature
range
Operating: 0°C to 50°C
Storage: -20 to +65°C (with no icing or condensation)
Ambient humidity range Operating:35 to 85%RH
Storage: 35 to 85%RH (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance Test sort B
Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration: 15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10
Vibration direction: up and down/front
and behind/left and right
Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration: 15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10
Vibration direction: up and down/front
and behind/left and right
Shock resistance Test sort1
Impact force: 150 m/s
2
Test direction: up and down/front and
behind/left and right
Impact force: 150 m/s
2
Test direction: up and down/front and
behind/left and right
Noise
immunity
Fast Tran-
sient Burst
• DC power
Direct infusion: 2kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms/0.75ms, Period: 300ms, Application time: 1 min
• I/O line
Direct infusion: 1kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms/0.75ms, Period: 300ms, Application time: 1 min
Grounding
Type D grounding (100ȍ or less grounding resistance)
*2
External
Features
Dimensions 190 mm × 115 mm × 182.5 mm
Note Height: Including the rubber feet at the base.
Weight Approx.
3.2 kg
Approx.
3.4 kg
Approx.
3.4 kg
Approx.
3.2 kg
Approx.
3.4 kg
Approx.
3.4 kg
Degree of protection IEC60529 IP20
Case material Cover: zinc-plated steel plate
Side plate: aluminum (A6063)
Sensor Controller Series FH-3000 series FH-1000 series
Type High-speed Controller (4 cores) Standard Controller (2 cores)
Sensor Controller Model FH-3050 FH-3050-10 FH-3050-20 FH-1050 FH-1050-10 FH-1050-20

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
