3 - 7
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-1 Sensor Controller
3
3-1-1 FH-1000/FH-3000 Series
Dimensions
19.5 143
115
24 141
Four, M4 mounting holes
with a depth of 4.5 mm
19.2 143
182.5
24
141
190
20.1
Four, M4 mounting holes
with a depth of 4.5 mm
26.7 148.5
10.5 94
66.2
38.1
Four, M3 mounting holes
with a depth of 4.5 mm
Sensor Controllers
FH-series Box-type
FH-3050/-3050-10/-3050-20
FH-1050/-1050-10/-1050-20
(Unit: mm)
* The 2-camera type has only one Ethernet
connectors.
* The 2-camera type has only two camera connectors,
and the 8-camera type has eight camera connectores.
