3 Configuration
3 - 20
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Current
consump-
tion
When con-
nected to a
Controller
Connected to 2 cameras 4.0 A max. 5.5 A max.
Connected to 4 cameras ---
Connected to 8 cameras ---
When not
connected
to a Control-
ler
Connected to 2 cameras 2.6 A max. 2.9 A max.
Connected to 4 cameras ---
Connected to 8 cameras
---
Built-in FAN No
Usage Envi-
ronment
Ambient temperature range Operating: 0°C to 50°C
Storage: -20 to +65°C
Ambient humidity range Operating and Storage: 35 to 85%RH (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration: 15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10 times
Vibration direction: up and down/front and behind/left and right
Shock resistance Test sort1
Impact force: 150 m/s
2
Test direction: up and down/front and behind/left and right
Noise
immunity
Fast Transient Burst • DC power
Direct infusion: 1kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms, Period: 300ms
Grounding ---
External
Features
Dimensions 209 mm × 80 mm × 182.3 mm
Note Height: Including the rubber feet at the base.
Weight Approx. 1.8 kg
Degree of protection IEC60529 IP20
Case material Steel plate
Sensor Controller Series FZ5-L series
Type Standard Controller
Sensor Controller Model FZ5-L350 FZ5-L355 FZ5-L350-10 FZ5-L355-10

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
