Omron GX-ID1611

A Appendix
A - 44
GX-series EtherCAT Slave Unit User’s Manual
• This object executes user adjustment. It writes upper adjustment value.
• To adjust, enter a voltage (or current) equivalent to 100% from a connected device to the terminal of
input point you want to adjust. (Set the input range in advance.)
• If you reset, it returns to the default setting.
• The value is adjusted or reset only when the specific value is written to sub-indexes 1 to 4. This
prevents erroneous execution and resetting. The specific values are:
"save" for execution, "rset" for resetting.
Writing values other than the above is invalid.
• A value 0000 0000 hex is indicated when reading.
• Stores the lower limit of user adjustment.
3112 hex Analogue Input Adjustment High Execute
Sub-index 0: Number of channel
Range: − Unit: − Default: 04 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-indexes 1 to 4: CH1-4 Adjustment High Execute
Range: − Unit: − Default: 00000000 hex Attribute: A
Size: 4 bytes (U32) Access: RW PDO map: Not possible
MSB LSB
evas
65 hex 76 hex 61 hex 73 hex
tesr
74 hex 65 hex 73 hex 72 hex
3113 hex Analogue Input Adjustment Low Value
Sub-index 0: Number of channel
Range: − Unit: − Default: 04 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-indexes 1 to 4: CH1-4 Adjustment Low Value
Range: − Unit: − Default: 0000 hex Attribute: −
Size: 2 bytes (INT16) Access: RO PDO map: Not possible
