3-6-23 Event
Time ascending Order Display: When this option is checked, the latest occurred event will be
displayed on the bottom and the event sequence No. and the
time will ascend from top to bottom, as shown below.
When this option is not checked, the event will be displayed in the descending order, i.e. the
latest occurred event will be displayed on the top, and event sequence No. and the time will
descend from top to bottom, as shown below.
3 Press the [OK] button to complete the setup, and adjust the position and the size of the Event
component.
No.
Date of
Occur
Date of
Occur.
Time of
Occur.
Checked
Time
Time of
Cancel
Event
content
Ascending order
by time, new
trigger events
are displayed on
the following.
Descending order
by time, new
trigger events are
displayed on the
top.
