Description of Operation Section 3-2
Note Online operations from the CX-Process Tool software are restricted as shown
in the following table during backup operations to a Memory Card for Loop
Controller Ver. 2.0.
Online operation from CX-Process
Tool
During
simple
backup
operation
Results on CX-
Process Tool
when operation
is not possible
Backup
continued/
interrupted
Data in Memory Card resulting
from simple backup operation
Download Downloading individual
function block ITEMs
(operation data)
Possible --- Possible Simple backup operation ends
normally, but the data may not be
backed up in the Memory Card.
Downloading block con-
nection information
Possible, but
backup may
not be normal
--- The data may not be backed up in
the Memory Card.
The data backed up in the Mem-
ory Card may not be correct. If
the data is not correct, a function
block database error (RAM) will
occur and A42410 will turn ON
when recovery is attempted.
Downloading LCU/LCB Not possible Communications
timeout error
Simple backup operation ends
normally, but the data will not be
backed up in the Memory Card.
Download-
ing individual
function
blocks
System
common
block
Not possible Communications
timeout error
Simple backup operation ends
normally, but the data will not be
backed up in the Memory Card.
Operation
blocks
Control
blocks
Sequence
control
blocks
Field ter-
minals
Download-
ing user link
tables
Selected
entries
Not possible FINS response
code of 3001
(cannot access
Memory Card)
returned.
Simple backup operation ends
normally, but the data will not be
backed up in the Memory Card.
All entries FINS response
code of 3001
(cannot access
Memory Card)
returned.
Simple backup operation ends
normally, but the data will not be
backed up in the Memory Card.
Upload Upload new Not possible Communications
timeout error
Possible Simple backup operation ends
normally.
Update previous Possible --- Simple backup operation ends
normally.
Verification Possible --- Possible Simple backup operation ends
normally.
Deleting registered blocks Possible --- Possible Simple backup operation ends
normally, but the data may not be
deleted in the Memory Card.
Setting operation cycle globally Possible --- Possible Simple backup operation ends
normally, but the data may not be
backed up in the Memory Card.
