Outline Section 1-1
1-1-13 List of Function Blocks
Note (1) The Function Blocks dealing with high-speed operation (operation cycle:
0.01, 0.02, and 0.05 seconds is possible) However, Not supported by the
LCB05D.
(2) LCB01/05 Ver.1.5 or later only.
(3) LCB05/05D only.
(4) LCB01/05 Ver.2.0 or later and LCB03 only.
(5) CS-series only.
(6) CJ-series only.
(7) LCB01/03/05 Ver. 3.5 or later only.
Category Type Block
Model
Block Name Function Allocatable Block
Address
System
Common
Block
000 System Com-
mon
Makes settings common to all function
blocks and outputs signals for the system.
000
Control
Block
Controller 001
(See note
1.)
2-position
ON/OFF
2-position type ON/OFF controller LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
002
(See note
1.)
3-position
ON/OFF
3-position type ON/OFF controller for heat-
ing/cooling ON/OFF control
011
(See note
1.)
Basic PID Performs basic PID control.
012
(See note
1.)
Advanced PID Performs PID with two degrees of freedom
control for enabling deviation/MV compen-
sation, MV tracking, etc.
013 Blended PID Performs PID control on the cumulative
value (cumulative deviation) between the
accumulated value PV and accumulated
value Remote Set Point.
014 Batch Flowrate
Capture
Functions to open the valve at a fixed open-
ing until a fixed batch accumulated value is
reached.
016 Fuzzy Logic Outputs up to two analog outputs based on
fuzzy logic performed on up to 8 analog
inputs.
LCB05/05D: 001 to 100
LCB03: 001 to 100
LCB01: 001 to 050
031
(See note
1.)
Indication and
Setting
Manual setter with PV indication and SP
setting functions
LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
032
(See note
1.)
Indication and
Operation
Manual setter with PV indication and MV
setting functions
033
(See note
1.)
Ratio Setting Ratio and bias setter with PV indication and
ratio setting function
034
(See note
1.)
Indicator PV indicator with PV alarm
External
Controller
Block
External
Control-
ler Block
045 ES100X Con-
troller Terminal
Performs monitoring and setting for an
ES100X Controller connected directly to
the RS-232C port on the Loop Control Unit.
LCB01/05: 601 to 632
LCB05D, LCB03: Not
supported.
