26
Outline Section 1-1
Operation
Block
Alarm/
Signal
restric-
tions/Hold
111
(See note
1.)
High/Low Alarm Provides the alarm contact outputs for the
high and low limits of single analog signals.
LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
112
(See note
1.)
Deviation Alarm Provides the alarm contact outputs for the
deviation of two analog signals.
113
(See note
1.)
Rate-of-change
Operation and
Alarm
Provides the alarm contact outputs for the
high and low limits of rate-of-change opera-
tion when the analog signal rate-of-change
is output.
115
(See note
1.)
High/Low Limit Limits the high and low limits of single ana-
log signals.
116
(See note
1.)
Deviation Limit Calculates the deviation between two ana-
log signals, and limits the deviation within
that range.
118
(See note
1.)
Analog Signal
Hold
Holds the maximum, minimum or instanta-
neous value of single analog signals.
Arithmetic 121
(See note
1.)
Addition or Sub-
traction
Performs addition/subtraction with gain and
bias on up to 4 analog signals.
122
(See note
1.)
Multiplication Performs multiplication with gain and bias
on up to 2 analog signals.
123
(See note
1.)
Division Performs division with gain and bias on up
to 2 analog signals.
126
(See note
1.)
Arithmetic Oper-
ation
Performs various math operation (trigono-
metric. logarithmic, etc.) on floating-point
decimal values converted (to industrial
units) from up to 8 analog inputs.
LCB05/05D: 001 to 100
LCB03: 001 to 300
LCB01: 001 to 050
127
(See note
1.)
Range Conver-
sion
Easily converts up to 8 analog signals sim-
ply by inputting the 0% and 100% input val-
ues and 0% and 100% output values.
LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
Functions 131
(See note
1.)
Square Root Performs square root extraction (with low-
end cutout) on single analog signals.
132
(See note
1.)
Absolute Value Performs non-linear (3 gain values) opera-
tion on single analog signals. Analog sig-
nals can also set as a dead band (with
different gap).
133
(See note
1.)
Non-linear Gain
(Dead Band)
Outputs the absolute value of single analog
signals
134
(See note
1.)
Low-end Cutout Sets output to zero close to the zero point
of single analog signals.
135
(See note
1.)
Segment Lin-
earizer
Converts single analog signals to 15 seg-
ments before the signals is output.
136
(See note
1.)
Temperature
And Pressure
Correction
Performs temperature and pressure correc-
tion.
Category Type Block
Model
Block Name Function Allocatable Block
Address
