27
Outline Section 1-1
Operation
Block (con-
tinued)
Time
Function
141
(See note
1.)
First-order Lag Performs first-order lag operation on single
analog signals.
LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
143
(See note
1.)
Rate-of-change
Limit
Performs rate-of-change restriction on sin-
gle analog signals.
145
(See note
1.)
Moving Average Performs moving average operation on sin-
gle analog signals.
147
(See note
1.)
Lead/Delay Performs lead/delay operation on single
analog signals.
148
(See note
1.)
Dead Time Performs dead time and first-order lag
operations on single analog signals.
149
(See note
1.)
Dead Time
Compensation
Used for Smith's dead time compensation
PID control
150 Accumulator for
instantaneous
value input
Accumulates analog signals, and outputs
8-digit accumulated value signals.
151 Run Time Accu-
mulator
Accumulates the operating time, and out-
puts the pulse signal per specified time.
153
(See note
1.)
Time Sequence
Data Statistics
Records time sequence data from analog
signals and calculates statistics, such as
averages and standard deviations.
LCB05/05D: 001 to 100
LCB03: 001 to 100
LCB01: 001 to 050
155 Ramp Program Ramp program setter for combining ramps
for time and hold values.
LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
156 Segment Pro-
gram
Segment program setter setting the output
values with respect to time.
157 Segment Pro-
gram 2
Segment program setting with wait function
for setting the output values with respect to
time
158
(See note
7.)
Segment Pro-
gram 3
Segment program setting with wait function
and bank (e.g., PID) switching function for
setting output values with respect to time.
601 Step Data Expansion settings for Segment Program 3
block (Block Model 158). Sets step data,
such as the time width and output value.
602 Bank Data Expansion settings for Segment Program 3
block (Block Model 158). Sets bank data,
such as the PID constants.
Category Type Block
Model
Block Name Function Allocatable Block
Address
To Next Page
