28
Outline Section 1-1
Operation
Block (con-
tinued)
Signal
Selec-
tion/
Switching
161
(See note
1.)
Rank Selector Selects the rank of up to 8 analog signals. LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
162
(See note
1.)
Input Selector Selects the specified analog signals speci-
fied by the contact signal from up to 8 ana-
log signals.
163
(See note
1.)
3-input Selector Selects and outputs one of three analog
input signals.
164
(See note
1.)
3-output Selec-
tor
Outputs one analog input signal in three
switched direction.
165
(See note
1.)
Constant Selec-
tor
Selects 8 preset constants by the contact
signal.
166
(See note
1.)
Constant Gen-
erator
Outputs 8 independent constants.
167 Ramped Switch Switches two analog inputs (or constants)
with a ramp.
168
(See note
2.)
Bank Selector Records the PID parameters (SP, P, I, D,
MH, ML) in up to 8 sets in advance, and
switches the PID parameter for
Basic/Advanced/Blended PID Blocks
according to the analog input range (zone)
or input bits.
169
(See note
2.)
Split Converter Inputs the MV from the Basic PID block or
Advanced PID block, converts the MV into
two analog outputs for V characteristics or
parallel characteristics (e.g., MV for heating
or cooling) and outputs them.
ITEM Set-
tings
171
(See note
1.)
Constant ITEM
Setting
Writes the constant to the specified ITEM
at the rising edge of the send command
contact.
LCB05/05D: 001 to 500
LCB03: 001 to 300
LCB01: 001 to 050
172
(See note
1.)
Variable ITEM
Setting
Writes the analog signal to the specified
ITEM at the rising edge of the send com-
mand contact.
174
(See note
1.)
Batch Data Col-
lector
Stores each of max. 8 analog inputs to
buffer by a certain timing within sequential
processing.
Pulse
Trai n
Operation
182 Accumulated
Value Input
Adder
Adds up to four accumulated value signals.
183 Accumulated
Value Analog
Multiplier
Multiplies analog signals by the accumu-
lated value signals.
184 Accumulator for
accumulated
value input
Converts 4-digit accumulated value signals
to 8 digits.
185 Contact
input/Accumu-
lated value out-
put
Counts low-speed contact pulses, and out-
puts 8-digit accumulated signals.
186 Accumulated
Value
Input/Contact
Output
Converts 4-digit accumulated value signals
to low-speed contact pulses before they are
output.
Category Type Block
Model
Block Name Function Allocatable Block
Address
