Outline Section 1-1
1-1 Outline
1-1-1 Outline
Various process operations, including PID control, can be performed for up to
500 blocks with the LCB05 and LCB05D, up to 300 blocks with the LCB03, or
up to 50 blocks with the LCB01. (See note.) Process operations include basic
logic sequence control and step-progression control. The Loop Controller can
also be used to implement an alarm/monitor terminal on a computer without
using PID control functions.
Note The maximum number of control loops is determined by the operation cycle.
In most cases, such as when each loop consists of an Ai4 Terminal, a Seg-
ment Linearizer, a Basic PID, and an Ao4 Terminal block the maximum num-
ber of control loops would be as shown in the following tables.
Loop Control Boards
CS1W-LCB01 and CS1W-LCB05 (LBC01/05)
Process-control CPU Units
CS1D-CPU@@P (LCB05D)
Loop-control CPU Units
CJ1G-CPU43P/44P/45P (LCB03)
Operation cycle Maximum number of loops
0.01 s 20 loops
0.02 s 35 loops
0.05 s 70 loops
0.1 s 100 loops
0.2 s 180 loops
0.5 s 250 loops
1 s 250 loops
2 s 250 loops
Operation cycle Maximum number of loops
0.1 s 80 loops
0.2 s 140 loops
0.5 s 250 loops
1 s 250 loops
2 s 250 loops
Operation cycle Maximum number of loops
0.01 s 20 loops
0.02 s 35 loops
0.05 s 70 loops
0.1 s 100 loops
0.2 s 150 loops
0.5 s 150 loops
1 s 150 loops
2 s 150 loops
