Description of Operation Section 3-2
Procedure
Creating a Function Block
Data File (Output to
Memory Card)
Set the DIP switch on the front of the CPU Unit as shown in the following
table, and then press the Memory Card Power Supply Switch for 3 s.
The function block file will be created and written to the Memory Card along
with the other backup files. For details, refer to 3-2-6 Simple Backup of Func-
tion Block Data to a Memory Card (LCB01/03/05 Ver. 3.0 or Later).
Note Use an OMRON Memory Card for the Memory Card. Operation may not be
dependable if a non-OMRON Memory Card (i.e., flash memory) is used.
Writing Function Block
Data Files Using FINS
Commands
• The BACKIPE1.PRM file made in advance can be written to the Loop
Controller by using a FINS command (2203).
• It is not necessary to use the DIP switch or Memory Card Power Supply
Switch on the front panel of the CPU Unit.
• If a FINS command (2203) is sent while the Loop Controller is operating,
Loop Controller operation will stop.
• CPU Unit operation will continue.
• LCB operation will stop.
DIP switch on front of CPU Unit
Pin 7 Pin 8
ON OFF
Loop Controller
Function
block data
flash memory
Memory Card power supply switch
Memory Car
All data
CPU Unit
Back up
