Omron SYSMAC CS Series User Manual

220
Description of FINS Commands Section 6-3
(3) Set the first packet to at least 90 bytes including the header data (90
bytes).
(4) The maximum write data length depends on the network it will pass
through. For Ethernet networks and the peripheral bus, the maximum is
900 bytes, and for SYSWAY, the maximum is 516 bytes.
(5) The response code for any other FINS commands will be 0x0001 from
the first packet until the last packet has been successfully received.
(6) After the last packet has been successfully received, it will not be possible
to execute a hot start or a cold start without restarting the Loop Controller
or cycling the power supply. In that case, the FINS response code will be
0x2605.
0x110C Other item parameter error
• The directory length is not 0.
• The parameter specification is incorrect.
• The Unit model is different in the backup data and the recov-
ery location.
• Command ended in one FINS frame (parameter: 0x0001
and bit 15 ON).
• Incorrect write data length: A write data length for a FINS
command is not in the following range:
- First packet: 90 bytes (See note 3.) ≤ Write data
length ≤ 900 bytes (See note 4.)
- Second packet: 0 bytes ≤ Write data length ≤ 900
bytes (See note 4.)
• A FINS command for which the last backup item is specified
is received while function blocks are being replaced. (In this
case, the function block replacement function will be forced
to stop.)
• The version is not applicable for the firmware that includes
LCBs.
0x2106 The file does not exist on the specified file device.
• The second or later packet was received without the FINS
for the first packet being completed properly.
0x250F A memory error has occurred.
• Error occurred in checksum.
• Failure occurred during backup to FROM.
0x2606 Error in command
The file name is not BACKUPE1.PRM.
Response code Meaning
