Omron SYSMAC CS Series User Manual

37
Outline Section 1-1
MV LImit Alarm Stop switch and MV
Alarm Control Stop switch for general
Control blocks
Not sup-
ported
Supported Supported Supported Supported Supported
Easy backup of function block data
from Loop Controller to Memory Card
Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
Memory Card backup for tag settings,
comments, and user link table con-
nection information prepared using
CX-Process Tool
Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
First or second reference input match
selection for Segment Program 2
(Block Model 157) start
Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
Synchronization of Segment Program
2 (Block Model 157)
Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
Hot start enabled time setting Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
Secondary loop anti-reset wind-up
with cascade control
Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
Added Split Converter block (Block
Model 169) input range setting from
0.00 to 100.00%
Not sup-
ported
Not sup-
ported
Supported Supported Supported Supported
Added field terminal blocks --- --- AI 4-point
Terminal
(PTS51/52)
AI 8-point
Terminal
(PTS55/56)
AI 4-point
Terminal
(PDC55)
AO 2-point
Terminal
(DA021)
AI 4-
point/AO 2-
point Termi-
nal
(MAD42)
AI 2-point
Terminal
(PTS15/16,
PDC15)
AI 16-point
Terminal
(AD161
In addition
to the ones
shown to
the left, the
following
field termi-
nal blocks
were
added: AI 4-
point Termi-
nal
(PH41U)AI
4-point Ter-
minal
(AD04U)AI
4-point Ter-
minal
(ADG41)
---
Other added function blocks Not sup-
ported
Not sup-
ported
Not sup-
ported
Switch
Instrument
block (Block
Model 225)
--- ---
Wireless debugging function
(Allows the user to enter pseudo-
inputs to a function block's PVs from
the CX-Process Tool or HMI I/F.)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
MV tight shut function
(An analog output terminal can be a
tight shut output to the CPU Unit's I/O
memory from a user link table.)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
MV analog output reversing function
(A field terminal (analog output termi-
nal) can be inverted to the CPU Unit's
I/O memory from a user link table.)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
RUN/STOP function
(Can execute a RUN or STOP com-
mand for only one PID function, either
the Basic PID (Block Model 011) or
Advanced PID (Block Model 012)).
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Item Ver. 1.0 Ver. 1.5 Ver. 2.0 Ver. 3.0 Ver. 3.5 Ver. 3.6
