52
Specifications Section 1-3
Recovery from flash memory to RAM Automatic at power ON if startup mode is set for a cold start, or
executed from CX-Process Tool (as required).
Influence on CPU Unit cycle time Loop Control Boards (CS1W-LCB01/05): 0.8 ms max. (Depends
on function block contents.)
Process-control CPU Units (CS1D-LCB05D): 25 ms max.
(Depends on function block contents.)
For details, refer to Example of the Influence of the Process-control
CPU Unit’s Loop Controller on Normal Cycle Time on page 41.
Loop-control CPU Unit (CJ1G-CPU@@P): 0.8 ms max. (Depends
on function block contents.)
Current consumption (supplied from Power Supply
Unit)
Loop Control Board: 0.22 A at 5 V DC
Process-control CPU Unit (CPU Unit element): 0.82 A at 5 V DC
Loop Control element: 0.22 A at 5 V DC
Loop-control CPU Unit: 1.06 A at 5 VDC
Note: Increased by 150 mA when NT-AL001 Link Adapter is used.
Standard accessories None
Item Specification
