7-6SectionPulse Outputs
99
Note Set the pulse output mode for each output in User Setup Area words DM 6613
and DM 6614.
Function Description Processing for PV
Pulse outputs The pulse outputs can be used for positioning or speed control
at a fixed duty ratio. Select one of four pulse output modes:
Relative pulse output, linear absolute pulse output, ring
absolute pulse output, and electronic cam.
Target value interrupts (note 2)
or bit pattern outputs for range
comparisons for PV of pulse
output.
One-shot pulse
outputs
Pulse output turned ON for only the specified interval (0.01 to
9,999 ms.
None
Pulse output
counter timer
Enables using the pulse output counter as a timer using the
one-shot pulse output timer.
Note: Pulses are not output for this mode and the specified port
cannot be used for pulse output.
Target value interrupts or bit
pattern outputs for range
comparisons for PV of pulse
counter.
Note 1. The processes listed in the following table can be performed for the PV of a
pulse output, pulse output counter timer, or one-shot pulse output elapsed
time.
2. Cannot be combined with pulse output in independent mode.
Process Description
Target value
interrupts
A subroutine is executed as interrupt processing when the
high-speed counter PV equals a target value.
Bit pattern
outputs for range
comparisons
A user-set bit pattern is output internally when the high-speed
counter PV is within a specified range.
